A community for users of the awesome, open source, free, animation, modeling, procedural generating, sculpting, texturing, compositing, and rendering software; Blender.
Rules:
- Be nice
- Constructive Criticism only
- If a render is photo realistic, please provide a wireframe or clay render
founded 2 years ago
MODERATORS
2
Let me know your thoughts, I'm always keen for feedback ๐
3
4
5
6
This book SUCKED. And not due to its informational value!!!
It was because the pages tended to pop off. It's a shitty binding, see?
The publisher, Not a Number (aka Blender's custodian corp) issued a recall, and offered to do spiral binding on these things. I was a university entrant. Book swappage could have been expensive. Didn't do it.
So I have a book that creaks. Half of it dedicated to turbo rad late 1990s art.
("Blender v1.5 Manual", by Ton Roosendaal, published by Not a Number in 1998, ISBN 90-76519-01-3)
8
9
10
11
13
14
15
Hello yall ! I am asking for your opinion on node editing, more precisely on creating straight paths with reroute nodes.
I find the built-in way of creating straight paths with reroute quite weird. If I'm not mistaken, it is :
- Click-drag to create the connection
- Shift + Right-click-drag to create a reroute.
- G and drag to place the reroute (repeat until path is made of 90ยฐ angles)
Now when it's time to clean up messy noodles, it makes sense : you don't need the first step and you can join multiple noodles with the Shift + Right-click-drag to go quicker. But when I create straight path from the start, I find it weird to first make the full path and then divide it.
I would have liked a feature to 'extrude' from reroute nodes so I can build the straight path step by step instead, so I made a small script to add this as a shortcut : when i press 'E', it adds a reroute connected to the last reroute/node selected. I'll try to add a gif to show what I mean, and I'll leave the code if anyone wants to try.
My question is : am I alone on this or does it make sense ? Did you too find the way reroute works a bit weird or did it always made perfect sense to you ? Or do you avoid straight paths entirely ? (Or is there some other way to work with reroutes that i'm not aware of ?)
Anyway, here is the code if needed (to use it, save it in a .py file, and in the Preferences/Addons tab, choose Install from disk and select your file) :
bl_info = {
"name" : "Extrude Noodles",
"blender" : (3, 60, 0),
"category" : "Node",
}
import bpy
class NodeConnectedReroute(bpy.types.Operator):
bl_idname = "node.add_connected_reroute"
bl_label = "Add connected reroute (Extrude) V4"
bl_options = {'REGISTER', 'UNDO'}
def execute(self, context) :
# Get node tree
nt = context.material.node_tree
# Get active node
node = bpy.context.active_node
# OPTION A - Create a not connected reroute
# in case there is no active node or it's not selected or it has no outputs
if not node or not node.select or not node.outputs.keys() :
bpy.ops.node.add_node(use_transform=True, type="NodeReroute")
return bpy.ops.transform.translate('INVOKE_DEFAULT')
# OPTION B - Create a reroute and link it to the active and selected node
# Add a reroute and connect it to current node first output
bpy.ops.node.add_node(use_transform=True, type="NodeReroute")
reroute = bpy.context.active_node
nt.links.new(reroute.inputs[0], node.outputs[0])
return bpy.ops.transform.translate('INVOKE_DEFAULT') # Returns that calls for movement.
def menu_func(self, context) :
self.layout.operator(NodeConnectedReroute.bl_idname)
# Store keymaps outside any function to access it any time
addon_keymaps = []
# When addon is enabled
def register() :
# Register the operator
bpy.utils.register_class(NodeConnectedReroute)
# Register its menu function in the correct menu
bpy.types.NODE_MT_node.remove(menu_func)
bpy.types.NODE_MT_node.append(menu_func)
# Create addon map
wm = bpy.context.window_manager
# Check if keyconfigs are available
kc = wm.keyconfigs.addon
if kc :
# Create a keymap in Node Editor context
km = wm.keyconfigs.addon.keymaps.new(name="Node Editor", space_type='NODE_EDITOR')
# Add a keymap item for simple extrude
kmi = km.keymap_items.new(NodeConnectedReroute.bl_idname, 'E', 'PRESS')
addon_keymaps.append((km, kmi))
# When addon is disabled
def unregister() :
# Do register in reverse order
for km, kmi in addon_keymaps:
km.keymap_items.remove(kmi)
addon_keymaps.clear()
bpy.utils.unregister_class(NodeConnectedReroute)
bpy.types.NODE_MT_node.remove(menu_func)
16
17
18
Hi, guys! ๐๐ผ When I try to switch to Material preview in Blender my program crashes!
Who knows what can I do with it? ๐ค
19
Hi all, I wanted to show some snippets of a project I'm working on. Something I'm calling GuitarNodes, a Geometry Nodes setup for making a procedurally customizable guitar that's easy to animate in Blender.
Here's a brief showcase of the features I've put into it:
Modular Parts
With Menu Switch nodes, it's easy to have swappable parts for the guitar. I've only (crudely) modeled one set at the time, but it's easy to see how a user could keep individual parts in separate collections to switch through. I also plan to make a second (crude) set to alternate between
Body
- Simply choose what body mesh you want
- Can be translated and rotated with gizmos
Headstock
- Choose desired headstock
- Origin for object is at the nut so that it attaches directly to fretboard
Tuning Pegs
- Note that there is a difference between L and R pegs
- Follows an adjustable guide mesh to stick to headstock
- Guide mesh can have individual rows of points(pegs) spaced apart more/less in X direction with gizmos
- Can switch between a guide mesh and curve, where the curve is for in-line pegs
- I don't have the line nodes done yet but it'll behave similarly
- String ends can be adjusted in normal Z direction to match custom peg height
- Can switch between a guide mesh and curve, where the curve is for in-line pegs
- Guide mesh can have individual rows of points(pegs) spaced apart more/less in X direction with gizmos
Output Jack
- Can be rotated, follows a guide empty and faces the normal of the guitar body
- Could also be modular if that's a detail you want to have
Tone Knobs
- Follows a guide curve that resamples to fit number of knobs
- You can edit this curve shape in order to arrange the knobs to your liking
- Will also be modular, such that you can change all of the knobs
Bridge
- Also modular
- Bridge can be moved in Y direction across the body with gizmo
- String ends can be adjusted in Z direction to match custom bridge height with gizmo
Saddle
- Automatically connects strings to bridge
- Also modular
- Can be rotated with gizmo
Neck and Fretboard
- Uses profile curves at nut, 12th fret, and end of fretboard
- Adjustable fret count
- Frets are spaced formulaically
- Minimal UI
- Shows measurement of string scale and the fretboard
Strings
- Adjustable count
- Adjustable gauges
- Tuning-based frequency oscillation in X direction (menu switch)
- Flip string order for left/right handed
- Adjustable oscillation intensity for varied strumming
- Adjustable fretted note values per string
- As the fretted note gets higher, the center of string oscillation moves accordingly
- As the fretted note gets higher, the oscillation frequency increases accordingly
Next plans (v0.8ish - 1.0):
- Adding Z-dimension to oscillation for more realism
- Add per-fret string translation that slightly increases string frequency for bending
- Custom guitar body, drawn with grease pencil (shoutout to Joey C for the inspiration!)
- I need help getting the points which the Tone Knobs instance at: they currently do not rotate to point the Z in the normal direction of the body. Instead, they all seem to match the first point's Z direction only. I want each point to recognize the normal of the nearest faces it's stuck to
- Adding a moveable pickguard whose Z-axis points in the body's normal direction
- Probably going to use a guide empty
- Might also implement custom designs with grease pencil
- Adjustable Z-direction with gizmo
- Player UI
- Shows chord chart for finger placements based on the current lowest fretted note
- Outlier high fretted notes will be shown next to the chart
- Shows chord chart for finger placements based on the current lowest fretted note
Further out plans
- Simulation nodes for strings, so that you can have oscillation decay over time
- Simulation nodes that interact with a plectrum object, so they can be literally strummed (probably gonna need a bit of help, too!)
- Better procedural materials
- Is it possible to use a For Each Element zone to change string material based on its position/diameter (i.e. thicker strings are wound)
- How much of this requires knowledge of handling UVs through geo nodes?
- Simulation nodes for painting custom materials on guitar (or just a good setup for other users to vertex paint it)
- Possible driver UI that changes a lot of these values, so that you don't have to go into the nodes to change things
- Want to implement a tablature-style tracker
- Automatically keys the string fret values to match the song's rhythm, accounting for framerate
- Implement a whammy bar that affects strings
- Any other feedback that I like enough to implement myself
20
21
22
Just a little project to reacquaint myself with sculpting after some time away from Blender. I'm pretty proud with how this one turned out.
23
To be honest, I'm incredibly pleased with the result. I spent half a day with the overall structure, and in general learning how to blender, and another half with actual sculpting. I made many mistakes and had to go back. I even messed-up in the end. This is too heavy I believe, and the topology is terrible because I wasn't constantly re-meshing (I wasn't paying much attention to the tutorial)
24
25
